MODEL |
T5500-48 Plus |
|
Capacity |
5.5KVA/5.5KW |
|
Parallel Capability |
YES,12 Units |
|
INPUT |
|
|
Nominal Voltage |
230VAC |
|
Acceptable Voltage Range |
170-280VAC(For personal Computer);90-280vac(For Home Appliances) |
|
Frequency |
50/60 Hz(Auto sensing) |
|
OUTPUT |
|
|
Nominal Voltage |
220/230VAC±5% |
|
Surge Power |
11000VA |
|
Frequency |
50/60Hz |
|
Waveform |
Pure Sine wave |
|
Transfer Time |
10ms(For personal Computer);20ms(For Home Appliances) |
|
Peak Efficiency(PV to INV) |
96% |
|
Peak Efficiency(Battery to INV) |
93% |
|
Overload Protection |
5s@>=150% load; 10s@110%~150% load |
|
Crest Factor |
3:1 |
|
Admissible Power Factor |
0.6~1(inductive or capacitive) |
|
BATTERY |
|
|
Battery Voltage |
48VDC |
|
Floating Charge Voltage |
54VDC |
|
OverCharge Protection |
63VDC |
|
Charging Method |
CC / CV |
|
Solar Charger & AC Charger |
|
|
Solar Charger Type |
MPPT |
|
Max.PV Array Power |
5500W |
|
Max.PV Array Open Circuit Voltage |
500VDC |
|
PV Array MPPT Voltage Range |
120VDC~450VDC |
|
Max.Solar Input Current |
18A |
|
Max.Solar Charge Current |
100A |
|
Max.AC Charge Current |
60A |
|
Max.Charge Current |
100A |
|
PHYSICAL |
|
|
Dimensions,D x W x H(mm) |
448x295x122 |
|
Package Dimensions,D x W x H(mm) |
540x390x210 |
|
Net Weight(Kg) |
10 |
|
Communication Interface |
RS485/ RS232 / Dry-contact |
|
ENVIRONMENT |
|
|
Operating Temperature Range |
(-10°C to 50°C) |
|
Storage Temperature |
(-15°C ~ 50°C) |
|
Humidity |
5% to 95% Relative Humidity ( Non-condensing ) |
