Model | 65505(F116Q1) |
65605(F116Q3) | |
Installation | Top-mounted |
Inlet/outlet | 1"M |
Drain | 3/4" NPT |
Brine line connector | 3/8" M |
Base | 2.5"-8NPSM |
Riser pipe | 1.05"OD |
Water treatment capacity | 5 m³/h |
Tank diameter range | 6"~18" |
Water pressure | 0.15MPa~0.6MPa |
Water temperature | 5℃~50℃ |
Water turbidity | Down flow regeneration<5FTU |
Power adapter | Input AC100~240V/50~60Hz
Output DC12V/1.5A |
Main Application And Applicability
Used for softening or demineralisation water treatment systems.
It is suitable for the residential softening system.
For more information, please refer to the manual book supplied with the control valve.
