When you consider purchasing this system, you need to know the following information as it is very important. This system requires a pretreatment set up for it to perform like it was designed to. The pretreatment setup is not guaranteed to work unless recommended by a sales agent according to the water analysis report from a lab.
A water analysis report is very important as it determines the pretreatment setup needed to be installed before the reverse osmosis system. As you can see on the sketch above, the pretreatment consists of a Sand/Glass Filter, Carbon Filter, and Antiscalant Dosing system.
Pretreatment setups can consist of even more items installed before the reverse osmosis system. Below is a list of items that could be required as per the water analysis report.
Once all the equipment has been purchased, you will need a qualified technician to complete the setup. We have qualified technicians trained by the equipment manufacturers to do the installation running of the setup. Should you require us to install the system for you, a quote with the installation fee will be sent to you by the sales agent in charge.
| Component | Details |
|---|---|
| 1. Pumps |
High Pressure Pump: LQDL4-14, 380v 50hz, 3P Q=3.5m³, H=118m, 3KW 3P Raw Water Pump: EHM 4-6; Q=3.5m³, H=50m, 1.1KW 3P |
| 2. SS304 Membrane Housing | 4040 × 8 pcs |
| 3. RO Membrane | 4040 × 8 pcs |
| 4. Filter Housing | 20" Jumbo Big Blue — 2 pcs |
| 5. Valves |
Brass Solenoid Valve: Inlet 1.2", Flush 1" Brass Globe Valve: DN15 × 2 pcs, DN20 × 1 pc |
| 6. Coated Electric Box | 1 pc |
| 7. Pressure Components |
Pressure Switch: -0.5~3 bar × 1 pc, 5~30 bar × 1 pc Pressure Gauge: Panel Type: 1 MPa × 1 pc, 2.5 MPa × 2 pcs |
| 8. UPVC Pipe | PN16 — 1 lot |
| 9. Flow Meter |
Waste Water: 1–10 GPM × 1 pc Product Water: 2–20 GPM × 1 pc |
| Parameter | Value |
|---|---|
| Model | SA-2T |
| Capacity | 2T/H |
| Power KW | 2.2KW |
| Inlet pressure | 3BAR |
| Running Pressure | 8-10BAR |
| Voltage | 380v 50hz, 3P |
| Membrane Recovery rate | 15%/ pcs |
| Desalinization rate | 95%-98% |
| System recovery | 50% |
| Inlet pipe size | 1.2" |
| Product water pipe size | 1" |
| Waste water pipe size | 1" |
| System power consumption | 5KW |
